JZ-DMT Type Cable Firestop Sealing Compound (A0-A60 Class)

Composition

  • JZ-DMT Firestop Sealing Stuff Part A (Powder)

  • JZ-DMT Firestop Sealing Stuff Part B (Liquid)

  • JZ-PD06 Expand Retaining Compound

Technical Data

  • Fire Rating: A0-A60

  • Water Tightness: 0.30Mpa

  • Air Tightness: 0.0250Mpa

  • Maximum Dimension of Steel Sleeve: 800x300x200mm

  • Maximum Cable OD: Φ63.8mm, with maximum cable occupancy of 25.1%

  • Mixing Proportion (Powder:Liquid): 3:2

Approved by

CCS, ABS, BV, LR, NK, RS, and MED



Installation Guidance

JZ-DMT Type Cable Transit Installation Guidance (youtube.com)
