HK-24 Type Ultralight Fireproof Putty Cable Transit（A0-A60 Class）

Composition

  • HK-24 Type Ultralight Fireproof Putty: New formula⸺lighter and better protection

Technical Data

  • Fire Rating: A0-A60

  • Maximum Dimension of Cable Coaming: L806mm×W306mm, φ300mm

  • The max. cable occupying rate is 40%, the max. approved cable OD is 94mm

Product Features

  • Low density, ultra lightweight

  • Single component, use without mixing

  • Soft putty, hardness not affected by environment temperature; quick, easy and flexible installation, can greatly inprove working efficiency

  • Halogen free and asbestos free, will not release harmful gases in the fire

Approved by

CCS, ABS, DNV, NK, RINA and BV

Installation Guidance

HK-24 Type Cable Transit Installation Guidance - YouTube
